Spec Sheet - Style Drawer Powered Vertical Organizer

Style Drawer Powered Vertical Organizer

Powered Vertical Organizer


Here are the key specifications for the Style Drawer Powered Vertical Organizer:

Cabinet Specifications
Internal Cabinet Depth 19 7/8 - 20 7/8"
Cabinet Opening Width more than 9"
Cabinet Opening Height 27"
Width of Pullout Assembly 9"

Features
Electrical Listing ETL Listed, CSA Listed with Interlock Box
Interlocking Safety Features Manual Reset Thermostat, Interlock Box (optional)
Electrical Connection Hardwired
Cage Material White Metal
Available Outlet Finishes White, Black or Stainless Steel
Available Wood Finishes Walnut or Maple
Warranty 2 Years
Country of Origin Made in Mexico

Receptacle Specifications
Tamper Resistant Yes
Amperage

AC: 20 amps @ 120 VAC (combined)
USB: 3.6 amps @ 5 VDC

Part Numbers

0290-620321

2 AC - GFCI, 2 AC & 2 USB-A

0290-620321-U

4 AC & 4 USB-A

0290-620321-I

2 AC - GFCI, 2 AC & 2 USB-A with Interlock Box

0290-620321-UI

4 AC & 4 USB-A with Interlock Box

Resources/Downloads


  1. Mounting Diagrams
  2. DXF and STEP Files
  3. 3D Animation - Style Drawer Vertical Organizer
  4. Electrical Planning Guide (Coming Soon)
  5. Installation Manual

Literature

  1. Style Drawer Powered Vertical Organizer Literature
  2. Docking Drawer Literature
